Save installation time and money with PoE.

 Power over Ethernet 802.3at
The Intellinet 16-Port Gigabit Ethernet PoE+ Switch supports the IEEE 802.3at protocol and is designed to inject up to 30 watts of power per port*. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power, thus eliminating the time and expense of electrical rewiring and minimizing the unsightly clutter caused by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short-circuit, overload and high-voltage protection function, your equipment is well-protected. For devices that are not 802.3at/af compliant (legacy wireless access points or network cameras), we suggest the use of an Intellinet PoE/PoE+ Splitter.

 Extreme Throughput
 With a backplane speed of 32 Gbps, there is plenty of performance available for your computers, servers and other networking devices.

 * Total PoE budget for this switch is 220 watts.





Boost your network speed.

Extreme Flexibility
Sixteen 10/100/1000 Mbps auto-sensing ports automatically detect optimal network speeds.

The auto features of this switch make installation plug and play and hassle free. Plus, it has Green Ethernet technology, allowing it to monitor power usage and turn off unused ports to save electricity.

Features
• 8-port Gigabit Ethernet switch expands your network in an instant
• Easy plug-and-play installation — simply power it up and start using it
• Eight 10/100/1000 auto-sensing ports automatically detect optimal network speeds
• High performance, half and full duplex, with zero packet loss
• Green Ethernet power-saving technology deactivates unused ports
• Supports any combination of 10 Mbps, 100 Mbps or 1 Gbps network devices
• Ultra-compact, fanless design ideal for home and office applications
• Store and forward switching architecture
• Compatible with all Windows and Macintosh systems

Specifications
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3ab (Gigabit Ethernet)
• IEEE 802.3x (Flow Control and Backpressure)
• IEEE 802.3az (Energy Efficient Ethernet)

General
• Connectors: 8 10/100/1000 Mbps RJ45 ports
• Cable: Cat3, 4, 5 UTP/STP
• Duplex modes: all ports (up to 200 Mbps)
• Uplink: all ports Auto MDI/MDX (Auto Uplink)
• Switch architecture: store and forward switch technology
• Filter/forward rate:
- 10BaseT: 14,880 pps (packets per second)
- 100Base-TX: 148,800 pps (packets per second)
- 1000Base-T: 1,488,000 pps (packets per second)
• MAC address table: 2,048 entries
• Buffer memory: 256 kBytes
• Jumbo frame support: 9 kB
• Backplane speed / switch fabric: 16 Gbps
• Certifications: FCC Class B, CE, RoHS

LEDs
• Power
• Link/Activity

Power
• External AC adapter: 5 V, 1 A

Environmental
• Dimensions: 140 (w) x 78 (l) x 28 (h) mm (5.5 x 3.07 x 1.1 in.)
• Weight: 0.33 kg (0.73 lbs.)
• Operating temperature: 0 – 40˚C (32 – 104˚F)
• Humidity: 10 – 90% (non-condensing)

Package Contents
• 8-Port Gigabit Ethernet Switch
• Power adapter
• User manual

TP-Link TL-SG1008D 8-Port Gigabit Desktop Switch, Retail Box, 1 year Limited Warranty

Product Overview:
What This Product Does
The TP-Link 8-Port Gigabit desktop switch TL-SG1008D provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Moreover, TL-SG1008D adopts lower power consumption design. With the innovative energy-efficient technology, the TL-SG1008D can save up to 80%* of the power consumption, making it an eco-friendly solution for your home or office network.
